Coupling female flatface FFH - DN12 - 3/4"BSP
Faster Flat-face quick coupler.
No spillage during connection and disconnection.
Connection system: Pushing the male coupling.
Disconnection system: Pulling back the sleeve
Shut-off system: Flat valve (male coupling with double valve).
Connectability: Without pressure.
Disconnection under pressure: Not allowed.
Partnumber:
FFH0834GASF
Package size:
1 st
Min. order quantity is:
1 st
Användingsområde
Hydraulic oil
DN
12.5 mm
Dimension A
G 3/4 BSP
Dimension B
85 mm
Dimension D
38 mm
Dimension X
34 mm
Flödeshastighet nominell LMin
110 lpm
Gänga inv.
G 3/4 BSP
ISO storlek
12.5
Modell kod
FFH08 34GAS F
Märke namn
Faster
Packningsmaterial
NBR, Polyurethane
Rostbeständighet
1000 hours salt spray UNI ISO 9227
Standard ISO
ISO 16028
Storlek
1/2 "
Temperatur max.
+100 °C
Temperatur min.
-25 °C
Tillverkningsmaterial
Steel
Tryck max.
350 bar
Tryckeliminator
No
Ytskiktbehandling
Zinc-Nickel plated
Package size
1 st
Barcode
330828
Gross weight
0,45 Kg
Net weight
0,45 Kg
Country of origin
ITA
Intrastat code
84812010
Faster Flat-face quick coupler.
No spillage during connection and disconnection.
Connection system: Pushing the male coupling.
Disconnection system: Pulling back the sleeve
Shut-off system: Flat valve (male coupling with double valve).
Connectability: Without pressure.
Disconnection under pressure: Not allowed.
Note: Opening 3D files requires a program that supports the file format
