Pump S45 JR-L-S75C-LS-25-20-NN-N-3-C3RE-A8N-NNN-JJJ-NNN

Pump S45 JR-L-S75C-LS-25-20-NN-N-3-C3RE-A8N-NNN-JJJ-NNN

Danfoss S45 variabel piston pump for open circuit.

Regulations: Pressure Compensator, Load sensing, PC controlled pressure.

Connections: SAE flange side connection in endcap.

Shaft- and o-ringsseals in Viton®.

Partnumber:

83024725

Package size:

1 pcs

Min. order quantity is:

1 pcs

Specifications
Dimensions and shipping

Antal monteringshål

Axel diameter

25,4 mm

Axel kod

Axel spline

15T 16/32 SAE-BB

Axeltyp

Spline

Axeltätning materiale

FKM/FPM (Viton®)

Bultcirkel

146 mm

Deplacement

75 cm3

Ekstra montering/endedæksel typ

Fläns SAE/DIN

3000 PSI

Fläns ingång

2 "

Fläns utgång

1 "

Föroreningsgrad max.

22/18/13 - ISO 4406

Förträngningsbegränsar

None

Kont. rotation max.

2400 rpm

Kontroll

Load sensing

Kontrolltyp

Modell

Frame J

Modell kod

JR-L-S75C-LS-25-20-NN-N-3-C3RE-A8N-NNN-JJJ-NNN

Monteringsfläns

SAE-B2

Märke namn

Danfoss

Oljeviskositet rekommanderad

9 - 110 cSt

Portplacering

Side

Reces

101,6 mm

Rotation max. vid max. tryck

2400 rpm

Rotationshastighet max.

2880 rpm

Rotationshastighet min.

500 rpm

Rotationsriktning

Left (CCW)

Sensor typ

None

Temperatur intermittent max.

+104 °C

Temperatur max.

+82 °C

Temperatur min.

-40 °C

Tryck kontinuerlig max.

260 bar

Tryck max.

350 bar

Utv. Splinesantal

Package size

1 pcs

Barcode

334105

Gross weight

26,80 Kg

Net weight

26,80 Kg

Country of origin

Intrastat code

84135061

Product information

Danfoss S45 variabel piston pump for open circuit.

Regulations: Pressure Compensator, Load sensing, PC controlled pressure.

Connections: SAE flange side connection in endcap.

Shaft- and o-ringsseals in Viton®.
