Stud fitting female - ø6L x M10x1 female
Stud fitting female - ø6L x M10x1 female
Partnumber:
XGAI06LM
Package size:
10
Min. order quantity is:
1
Angle
0 °
Corrosion resistance
1200 hours salt spray DIN EN ISO 9227
Diameter pipe
6 mm
L
26,5 mm
L1
34,5 mm
L2
19,5 mm
L3
12,5 mm
Material
Steel
Model code
XAI6L101ZN
Pressure max.
315 bar
REACH compliant
Yes
RoHs compliant
Yes
S1
14 mm
S2
14 mm
Safety factor
4
Series
L
Surface treatment
Zinc-Nickel plated
Temperature max.
+120 °C
Temperature min.
-40 °C
Thread T
M10x1
Thread inner metric
M10x1 MM
Thread outer metric
M12x1,5
d1
6 mm
d2
4 mm
Package size
10
Barcode
306877
Gross weight
0,02 Kg
Net weight
0,02 Kg
Country of origin
DEU
Intrastat code
73071110
Stud fitting female - ø6L x M10x1 female
