Screw coupling female RH - DN25 - M52x2 (38S)
Tube quick-coupling of screw-type.
Good for large oil-flows.
Partnumber:
RH25-1-S3852
Package size:
1 pcs
Min. order quantity is:
1 pcs
A
M52x2
Brand Name
Stauff
Connection
Screw
Diameter pipe
38 mm
Disconnection
Screw
Field of application
Construction Machinery
Flow rate nominal LMin
200 lpm
L1
125 mm
L3
22 mm
Material
Steel
Model code
QRC-RH-25-F-38S-S1-W3
Pressure burst min.
1150 bar
Pressure max. connected
420 bar
Pressurized connection
Allowed, max. 20 bar
SW1
55 mm
Sealing material
NBR
Series
S
Size
1 "
Spillage
2,84 ml
Standard DIN
DIN 3861
Surface treatment
Zinc-Nickel plated
Temperature max.
+100 °C
Temperature min.
-20 °C
Thread outer metric
M52x2
ØD2
38 mm
Package size
1 pcs
Barcode
357200
Gross weight
2,90 Kg
Net weight
2,90 Kg
Country of origin
DEU
Intrastat code
84812010
Tube quick-coupling of screw-type.
Good for large oil-flows.
