SAE100R7 2-tekst.kudosv. PETP-sisäp
5,0x9,3 207bar
Partnumber:
OL7-03
Package size:
10 m
Min. order quantity is:
1 m
Bend radius
30 mm
Brand Name
Mac Tubi S.p.A.
Color
Black
Diameter inner
5 mm
Diameter outer
9.3 mm
Hose size
3/16 "
Pressure burst min.
830 bar
Pressure max.
207 bar
Temperature max.
+93 °C
Temperature min.
-40 °C
Package size
10 m
Barcode
402518
Gross weight
0,057 Kg
Net weight
0,057 Kg
Country of origin
ita
5,0x9,3 207bar
Crimp dimensions OL7-03
|
Hose type |
Diamter - inch |
Hose coupling type |
Ferrule |
Crimp dimension - mm |
Skiving - int. |
Skiving - ext. |
Operating pressure |
|---|---|---|---|---|---|---|---|
| OL7-03 | 3/16 | PS03 | 8P4010-03 |
11.5 mm
0.0
0.2 |
No | No | 207 |
