Oil-Air cooler TT 25 rail AC

Oil-Air cooler TT 25 rail AC

NOTE! also requires TT rail connection kit.

Please order separately.

Partnumber:
ASATT25RA66
Package size:
1 pcs
Min. order quantity is:
1 pcs
Foot mounting TT 07-36 (heavy duty = mobile use)
Partnumber: ILLEFUSSTTHDK
Mounting feet set ASA-TT 07 - 25
Partnumber: ILLEFUSSTTK
TT-rail Connector Kit 90 degrees BSP1 1/4"
Partnumber: ILLZSET5G32
TT-rail Connector Kit Straight BSP1 1/4"
Partnumber: ILLZSET5G32A
TT-rail Connector Kit Mixed BSP1 1/4"
Partnumber: ILLZSET5G32B
Temperature control 12VDC
Partnumber: ILLZTC12-2K
Temperature control 24VDC
Partnumber: ILLZTC24-2K
Temperature switch BSP1/2" DIN-3P Set point 50C
Partnumber: ILLZTH4765K
Temperature switch BSP1/2" AMP Superseal 1.5 Set point 50C
Partnumber: ILLZTH5069K
Air flow
1,3 kg/s
Brand Name
ASA
By-pass valve
No
Current
1.17 A
Current type
AC
Depth
440 mm
Flow rate nominal LMin
250 lpm
Height
605 mm
Material
Aluminium
Model code
ASATT25RA66
Motor power
0,37 kW
Motor size
80 IEC
Noise level
71 dB-A
Pressure max.
26 bar
Protection class
IP 55
Shape
Air fin: wavy
Temperature max.
+80 °C
Temperature min.
-20 °C
Voltage
230, 400 V
Width
558 mm
Package size
1 pcs
Barcode
480601
Gross weight
Kg
Net weight
41,20 Kg
Country of origin
aut
Intrastat code
84186900

NOTE! also requires TT rail connection kit.

Please order separately.

Product datasheet
Manual
Product datasheet - 2
