OMVW 400 HYDRAULIK MOTOR
OMVW 400 HYDRAULIK MOTOR
Partnumber:
151B3121
Package size:
1 kpl
Min. order quantity is:
1 kpl
Brand Name
Danfoss
Contamination level max.
22/20/16 - ISO 4406
Continuous power max.
53.5 kW
Continuous rotation max.
500 rpm
Displacement
400.9 cm3
Drainport
G 1/4 BSP
Holes circle
224 mm
L
153 mm
L1
29 mm
L2
99 mm
Mounting flange
Wheel 180
Number of mounting holes
4
Oil viscocity recommended
20 - 75 cSt
Port position
Side
Pressure drop continuous max.
200 bar
Recess
180,0 mm
Shaft cone
1:10
Shaft diameter
60 mm
Shaft keyway
16,0 mm
Shaft type
Tapered
Temperature ambient max.
+90 °C
Temperature ambient min.
-30 °C
Torque continuous max.
1180 Nm
Working ports
G 1 BSP
Package size
1 kpl
Barcode
333828
Gross weight
35,00 Kg
Net weight
35,00 Kg
Country of origin
Intrastat code
84122981
