    NG10 4/3 valves Atos DKE with coil 230VAC

    Välj variant
    VÄLJ VARIANT
    VÄLJ VARIANT
    Artikelnummer Beskrivning Pressure T max. Voltage Current type Number of ways/positions
    DKE1710-C DKE-1710-X220-AC Atos solenoid valve cetop5 160 bar 230 V AC 4/3
    DKE1711-C DKE-1711-X220-AC Atos solenoid valve cetop5 160 bar 230 V AC 4/3
    DKE1713-C DKE-1713-X220-AC Atos solenoid valve cetop5 160 bar 230 V AC 4/3
    DKE1714-C DKE-1714-X220-AC Atos solenoid valve cetop5 160 bar 230 V AC 4/3
    DKE1714/L-C DKE-1714/L-X220-AC Atos solenoid valve Cetop5 160 bar 230 V AC 4/3
    Activation
    Manual emergency override, Solenoid
    Brand Name
    Atos
    Contamination level max.
    20/18/15 - ISO 4406
    Current type
    AC
    Flow rate nominal LMin
    150
    NG ISO-size
    NG10
    Number of ways/positions
    4/3
    Oil viscocity recommended
    15 - 100
    Plug type
    DIN EN 175301-803 Form A
    Pressure T max.
    160
    Standard ISO
    ISO 4401
    Temperature max.
    +80
    Temperature min.
    -20
    Torque tightening
    15
    Voltage
    230
