4/2 NG10 valves Atos DKE without coil

4/2 NG10 valves Atos DKE without coil

Vælg variant
VÆLG VARIANT
VÆLG VARIANT
Varenummer Beskrivelse Pressure T max. Number of ways/positions
DKE1610-X Atos solenoid valve cetop5 DKE-1610-X00-DC without coil 210 bar 4/2
DKE1610/A-X Atos solenoid valve cetop5 DKE-1610/A-X00-DC 210 bar 4/2
DKE1611-X Atos solenoid valve Cetop5 DKE-1611-X00-DC w/o coil 210 bar 4/2
DKE1613-X Atos solenoid valve cetop5 DKE-1613-X00-DC without coil 210 bar 4/2
DKE1614-X Atos solenoid valve cetop5 DKE-1614-X00-DC without coil 210 bar 4/2
DKE1614/A-X Atos solenoid valve cetop5 DKE-1614/A-X00-DC u with coil 210 bar 4/2
DKE1630/2-X Atos solenoid valve cetop5 DKE-1630/2-X00-DC, u/with coi 210 bar 4/2
DKE1631/2-X Atos solenoid valve cetop5 DKE-1631/2-X00-DC, u/with coi 210 bar 4/2
Activation
Manual emergency override, Solenoid
Brand Name
Atos
Contamination level max.
20/18/15 - ISO 4406
Flow rate nominal LMin
150
NG ISO-size
NG10
Number of ways/positions
4/2
Oil viscocity recommended
15 - 100
Pressure T max.
210
Pressure max.
350
Standard ISO
ISO 4401
Temperature max.
+80
Temperature min.
-20
Torque tightening
15
