Blind plugs - SAE 3000 PSI

Flange plug 1/2" SAE3000 - w/o o-ring

Flange plug 3/4" SAE3000 - w/o o-ring

Flange plug 1" SAE3000 - w/o o-ring

Flange plug 1.1/4" SAE3000 - w/o o-ring

Flange plug 1.1/2" SAE3000 - w/o o-ring

Flange plug 2" SAE3000 - w/o o-ring

SELECT VARIANT

Partnumber	Description	Flange	O-ring	Pressure max.
BSO3001	Flange plug 1/2" SAE3000 - w/o o-ring	1/2 "	18,64X3,53 mm	350 bar
BSO3002	Flange plug 3/4" SAE3000 - w/o o-ring	3/4 "	24,99X3,53 mm	350 bar
BSO3003	Flange plug 1" SAE3000 - w/o o-ring	1 "	32,93X3,53 mm	320 bar
BSO3004	Flange plug 1.1/4" SAE3000 - w/o o-ring	1.1/4 "	37,69X3,53 mm	280 bar
BSO3005	Flange plug 1.1/2" SAE3000 - w/o o-ring	1.1/2 "	47,22X3,53 mm	210 bar
BSO3006	Flange plug 2" SAE3000 - w/o o-ring	2 "	56,75X3,53 mm	210 bar

Brand Name

Havit

Corrosion resistance

480 hours salt spray DIN EN 9227

Flange SAE/DIN

3000 PSI

Material

Steel

Shore

Standard ISO

ISO 6162-1

Standard SAE

SAE J518 Code 61

Surface treatment

Zinc-Nickel plated
