S580-20-27U barrel Tee UNF

Partnumber:

TOD-20-17/16

Package size:

0 pcs

Min. order quantity is:

1 pcs

Specifications
Dimensions and shipping

Brand Name

FOR

Corrosion resistance

1400 hours salt spray DIN EN ISO 9227

Diameter pipe

20 mm

Dimension B

42 mm

Dimension B1

42 mm

Dimension C

49 mm

Dimension CH

32 mm

Dimension F

1.1/16-12 UNF

Dimension J

1.1/16-12 JIC

Dimension J1

1.1/16-12 JIC

Dimension T

20 mm

Dimension T1

20 mm

Material

Steel

Pressure max.

300 bar

Surface treatment

Electro-galvanized / White chromatized

Thread outer

1.1/16-12 JIC

Thread outer

1.1/16-12 UNF

Package size

0 pcs

Barcode

5704334274858

Gross weight

0,34 Kg

Net weight

0,34 Kg

Country of origin

ITA

Intrastat code

73071110

Product information
Measure sketch

S580-20-27U barrel Tee UNF

Note: Opening 3D files requires a program that supports the file format
