Banjo - ø12L x 3/8" BSP with WD seal NBR
Temperature/pressurereduction:
-40°C - +120°C = 0%.
+120°C - +150°C = 11%.
+150°C - +175°C = 15%.
+175°C - +200°C = 19%.
+200°C - +250°C = 28%
Partnumber:
FXRSW12LR38WD
Package size:
1 pcs
Min. order quantity is:
1 pcs
D1
12 mm
D2
22,8 mm
Diameter rør
12 mm
Gevind udvendig
G 3/8 BSP
Korrosions resistens
1200 hours salt spray DIN EN ISO 9227
L
24,5 mm
L2
17,5 mm
L3
32,5 mm
L4
16 mm
Materiale
Steel
Model kode
FI-RSW-12LR-WD-B-W3
Mærke navn
Stauff
Overfladebehandling
Zinc-Nickel plated
PN
400 bar
Pakningsmateriale
NBR
REACH compliant
Yes
RoHs compliant
Yes
S1
24 mm
S2
22 mm
Serie
L
Sikkerhedsfaktor
4
T
G 3/8 BSP
Temperatur maks.
+100 °C
Temperatur min.
-35 °C
Tryk maks.
400 bar
Vinkel
90 °
i
12 mm
Package size
1 pcs
Barcode
5704334835530
Gross weight
Kg
Net weight
0,139 Kg
Country of origin
deu
Intrastat code
73071110
Temperature/pressurereduction:
-40°C - +120°C = 0%.
+120°C - +150°C = 11%.
+150°C - +175°C = 15%.
+175°C - +200°C = 19%.
+200°C - +250°C = 28%
