Tandhjulsmotorer Casappa Polaris PLM20

0199801V - PLM20.11,2R0-82E2-LEA/EA-N-EL-DH Polaris motor

019984G5 - PLM20.6.3R0-82E2-LEA/EA-N-EL- DH Polaris motor, Casappa

01999811 - PLM20.16R0-82E2-LEA/EB-N-EL-DH Polaris motor, Casappa

01999812 - PLM20.20R0-82E2-LEA/EB-N-EL-DH Polaris motor, Casappa

01999813 - PLM20.8R0-82E2-LEA/EA-N-EL-DH Polaris motor, Casappa

01999814 - PLM20.14R0-82E2-LEA/EB-N-EL-DH Polaris motor, Casappa

01999815 - PLM20.25R0-82E2-LEA/EB-N-EL-DH Polaris motor, Casappa

VÆLG VARIANT

Varenummer	Beskrivelse	Shaft type	Number of mounting holes	Displacement	Mounting flange
0199801V	0199801V - PLM20.11,2R0-82E2-LEA/EA-N-EL-DH Polaris motor	Konisk	4	11.23 cm3	EU37 - 96x72
019984G5	019984G5 - PLM20.6.3R0-82E2-LEA/EA-N-EL- DH Polaris motor, Casappa	Konisk	4	6.61 cm3	EU37 - 96x72
01999811	01999811 - PLM20.16R0-82E2-LEA/EB-N-EL-DH Polaris motor, Casappa	Konisk	4	16.85 cm3	EU37 - 96x72
01999812	01999812 - PLM20.20R0-82E2-LEA/EB-N-EL-DH Polaris motor, Casappa	Konisk	4	21.14 cm3	EU37 - 96x72
01999813	01999813 - PLM20.8R0-82E2-LEA/EA-N-EL-DH Polaris motor, Casappa	Konisk	4	8.26 cm3	EU37 - 96x72
01999814	01999814 - PLM20.14R0-82E2-LEA/EB-N-EL-DH Polaris motor, Casappa	Konisk	4	14.53 cm3	EU37 - 96x72
01999815	01999815 - PLM20.25R0-82E2-LEA/EB-N-EL-DH Polaris motor, Casappa	Konisk	4	26.42 cm3	EU37 - 96x72

Brand Name

Casappa

Contamination level max.

19/17/14 - ISO 4406

Mounting flange

EU37 - 96x72

Number of mounting holes

Oil viscocity recommended

12 - 100

Port inlet

EU30

Rotation direction

Reversibel (CW/CCW)

Shaft cone

1:8

Shaft keyway

3,2

Shaft type

Konisk
