S615-16-21G elbow BSP

Varenummer:

VO-16-1/2

Pakke str.:

0 pcs

Min. bestillingsenhed er:

1 pcs

Tilbehør (1)

Bushing Ø16

Partnumber: B-16

Specifications
Dimensions and shipping

Angle

45 °

Brand Name

FOR

Corrosion resistance

1400 hours salt spray DIN EN ISO 9227

Diameter pipe

16 mm

Dimension B

28 mm

Dimension C

38.5 mm

Dimension CH

27 mm

Dimension F

G 1/2 BSP

Dimension J

7/8-14 JIC

Dimension T

16 mm

Material

Steel

Pressure max.

350 bar

Surface treatment

Electro-galvanized / White chromatized

Thread outer

7/8-14 JIC

Thread outer

G 1/2 BSP

Package size

0 pcs

Barcode

5704334033295

Gross weight

0,13 Kg

Net weight

0,13 Kg

Country of origin

ITA

Intrastat code

73071110

Product information
Measure sketch

S615-16-21G elbow BSP

Note: Opening 3D files requires a program that supports the file format
