Fläns 90gr SAE3000 DIN

Fläns 90gr SAE3000 DIN

Fläns 90gr SAE3000 DIN

Fläns 90gr SAE3000 DIN

Artikelnummer:

8369-16-28L

Förpackningsstorlek:

1 st

Minsta beställningskvantitet:

1 st

Specifications
Dimensions and shipping

Angle

90 °

Brand Name

Stauff

Corrosion resistance

800 hours salt spray DIN EN 9227

Diameter flange

44.5 mm

Diameter pipe

28 mm

Dimension A

2.37 mm

Dimension B

26.19 mm

Dimension I

54 mm

Dimension L

54.5 mm

Dimension T

28 mm

Dimension l1

62 mm

Flange

1 "

Flange SAE/DIN

3000 PSI

Material

Steel

Model code

CAG90-303-28L-W3

O-ring

32.93X3.53 mm

Series

L

Shore

90

Standard ISO

ISO 6162-1

Standard SAE

SAE J518 Code 61

Thread outer metric

M36x2

Package size

1 st

Barcode

243624

Gross weight

Kg

Net weight

Kg

Country of origin

deu

Product information
