Oil-Air cooler TT 16 rail AC

Oil-Air cooler TT 16 rail AC

Oil-Air cooler TT 16 rail AC

Partnumber:
ASATT16RA64
Package size:
1 kpl
Min. order quantity is:
1 kpl
Foot mounting TT 07-36 (heavy duty = mobile use)
Partnumber: ILLEFUSSTTHDK
Mounting feet set ASA-TT 07 - 25
Partnumber: ILLEFUSSTTK
TT-rail Connector Kit 90 degrees BSP1 1/4"
Partnumber: ILLZSET5G32
TT-rail Connector Kit Straight BSP1 1/4"
Partnumber: ILLZSET5G32A
TT-rail Connector Kit Mixed BSP1 1/4"
Partnumber: ILLZSET5G32B
Temperature control 12VDC
Partnumber: ILLZTC12-2K
Temperature control 24VDC
Partnumber: ILLZTC24-2K
Temperature switch BSP1/2" DIN-3P Set point 50C
Partnumber: ILLZTH4765K
Temperature switch BSP1/2" AMP Superseal 1.5 Set point 50C
Partnumber: ILLZTH5069K
Brand Name
ASA
By-pass valve
No
Current type
AC
Depth
414 mm
Height
465 mm
Material
Aluminium
Model code
ASATT16RA64
Noise level
73 dB-A
Pressure max.
26 bar
Pressure static max.
26 bar
Temperature ambient max.
+80 °C
Temperature ambient min.
-20 °C
Temperature working fluid max.
+80 °C
Voltage
230, 400 V
Width
462 mm
Package size
1 kpl
Barcode
500595
Gross weight
Kg
Net weight
28,10 Kg
Country of origin
aut
Intrastat code
84186900
