    • Oil-Air cooler TT 11 rail AC w. pressure by-pass

    Oil-Air cooler TT 11 rail AC w. pressure by-pass

    NOTE! also requires TT rail connection kit.

    Please order separately.

    Artikelnummer:
    ASATT11RA44BP
    Förpackningsstorlek:
    1 pcs
    Minsta beställningskvantitet:
    1 pcs
    Foot mounting TT 07-36 (heavy duty = mobile use)
    Artikelnummer: ILLEFUSSTTHDK
    Mounting feet set ASA-TT 07 - 25
    Artikelnummer: ILLEFUSSTTK
    TT Connectorset nominal size 25 Connector: G 1"
    Artikelnummer: ILLZSET5G25
    TT-rail Connector Kit Mixed BSP1"
    Artikelnummer: ILLZSET5G25B
    Temperature control 12VDC
    Artikelnummer: ILLZTC12-2K
    Temperature control 24VDC
    Artikelnummer: ILLZTC24-2K
    Tempvakt BSP1/2" DIN-3P 50° IP65
    Artikelnummer: ILLZTH4765K
    Tempvakt BSP1/2" AMP Superseal 1.5 50° IP69K
    Artikelnummer: ILLZTH5069K
    Air flow
    0,48 kg/s
    Brand Name
    ASA
    By-pass valve
    Yes
    Current
    0.73 A
    Current type
    AC
    Depth
    398 mm
    Flowrate nominal LMin
    150 lpm
    Height
    340 mm
    Material
    Aluminium
    Model code
    ASATT11RA44BP
    Motor power
    0,25 kW
    Motor size
    71 IEC
    Noise level
    63 dB-A
    Pressure max.
    26 bar
    Protection class
    IP 55
    Shape
    Air fin: wavy
    Temperature max.
    +80 °C
    Temperature min.
    -20 °C
    Voltage
    230, 400 V
    Width
    380 mm
    Förpackningsstorlek
    1 pcs
    Streckkod
    477669
    Bruttovikt
    Kg
    Nettovikt
    19,90 Kg
    Ursprungsland
    aut
    Intrastat artikelkod
    84186900

    NOTE! also requires TT rail connection kit.

    Please order separately.
