Faster FFH Female BSP

SELECT VARIANT
Partnumber Description Brand Name Size Material Pressure max.
FFH0218GASF Coupling female flatface FFH - DN03 - G1/8" Faster 1/8 " Steel 350 bar
FFH0414GASF Coupling female flatface FFH - DN06 - 1/4"BSP Faster 1/4 " Steel 350 bar
FFH0612GASF Coupling female flatface FFH - DN10 - 1/2"BSP Faster 3/8 " Steel 350 bar
FFH0638GASF Coupling female flatface FFH - DN10 - 3/8"BSP Faster 3/8 " Steel 350 bar
FFH0812GASF Coupling female flatface FFH - DN12 - 1/2"BSP Faster 1/2 " Steel 350 bar
FFH0834GASF Coupling female flatface FFH - DN12 - 3/4"BSP Faster 1/2 " Steel 350 bar
FFH1034GASF Coupling female flatface FFH - DN16 - 3/4"BSP Faster 5/8 " Steel 350 bar
FFH1058GASF Coupling female flatface FFH - DN19 - 5/8"BSP Faster 5/8 " Steel 350 bar
FFH121GASF Coupling female flatface FFH - DN20 - 1"BSP Faster 3/4 " Steel 350 bar
FFH1234GASF Coupling female flatface FFH - DN20 - 3/4"BSP Faster 3/4 " Steel 350 bar
FFH16114GASF Coupling female flatface FFH - DN25 - 1.1/4"BSP Faster 1 " Steel 350 bar
FFH161GASF Coupling female flatface FFH - DN25 - 1"BSP Faster 1 " Steel 350 bar
FFH20114GASF Coupling female flatface FFH - DN32 - 1.1/4"BSP Faster 1.1/4 " Steel 350 bar
Area of use
Hydraulic oil

Brand Name
Faster

Material
Steel

Pressure eliminator
No

Pressure max.
350

Sealing material
NBR, Polyurethane

Standard ISO
ISO 16028

Surface treatment
Zinc-Nickel plated

Temperature max.
+100

Temperature min.
-25
