OMH 400 HYDRAULIC MOTOR
OMH are light and compact and thus easy to install in machinery like forklifts, lawn mowers, lifts, loaders and excavators.
Partnumber:
151H1005
Package size:
1 st
Min. order quantity is:
1 st
Brand Name
White
C
G 1/4 BSP
Continuous power max.
10 kW
Continuous rotation max.
185 rpm
D
G 1/2 BSP
Displacement
396.8 cm3
Drainport
G 1/4 BSP
Holes circle
106.4 mm
Intermittent Effect Max.
12 kW
Intermittent Rotation speed Max.
225 rpm
Intermittent Torque Max.
700 Nm
L
198,1 mm
L1
54,8 mm
Mounting flange
SAE-A4 Magneto
Number of mounting holes
4
Oil viscocity recommended
20 - 75 cSt
Port position
Side
Pressure continous max.
200 bar
Pressure drop continuous max.
105 bar
Pressure intermittent max.
225 bar
Pressure peak max.
250 bar
Recess
82,5 mm
Sealing material
NBR
Shaft diameter
32 mm
Shaft keyway
10,0 mm
Shaft type
Cylindrical
Torque continuous max.
590 Nm
Working ports
G 1/2 BSP
Package size
1 st
Barcode
333717
Gross weight
12,80 Kg
Net weight
12,80 Kg
Country of origin
Intrastat code
84122981
OMH are light and compact and thus easy to install in machinery like forklifts, lawn mowers, lifts, loaders and excavators.
