Faster OGV

SELECT VARIANT

Partnumber	Description	Pressure max.	Flow rate nominal LMin
OGV1234NPSF	Snabbkoppling Hona DN20 Inv-3/4 NPSF typ Snap-tite 75	350 bar	120 lpm
OGV1234NPSM	Snabbkoppling Hane DN20 Inv-3/4 NPSF typ Snap-tite 75	350 bar	120 lpm
OGV161NPSF	Snabbkoppling Hona DN25 Inv-1 NPSF typ Snap-tite 75	350 bar	230 lpm
OGV161NPSM	Snabbkoppling Hane DN25 Inv-1 NPSF typ Snap-tite 75	350 bar	230 lpm
OGV20114NPTF	Snabbkoppling Hona DN32 Inv-1-1/4 NPTF typ Snap-tite 75	350 bar	320 lpm
OGV20114NPTM	Snabbkoppling Hane DN32 Inv-1-1/4 NPTF typ Snap-tite 75	350 bar	320 lpm
OGV24112GASFST	Skruvkoppling Hona Inv-G1.1/2" typ Snap-tite 75	350 bar	330 lpm
OGV24112GASMST	Skruvkoppling Hane Inv-G1.1/2" typ Snap-tite 75	350 bar	330 lpm
OGV24112NPTF	Snabbkoppling Hona DN38 Inv-1-1/2 NPTF typ Snap-tite 75	350 bar	330 lpm
OGV24112NPTM	Snabbkoppling Hane DN38 Inv-1-1/2 NPTF typ Snap-tite 75	350 bar	330 lpm
OGV322GASFST	Skruvkoppling Hona Inv-G2" typ Snap-tite 75	350 bar	570 lpm
OGV322GASMST	Skruvkoppling Hane Inv-G2" typ Snap-tite 75	350 bar	570 lpm
OGV322NPTF	Snabbkoppling Hona DN50 Inv-2 NPTF typ Snap-tite 75	350 bar	570 lpm
OGV322NPTM	Snabbkoppling Hane DN50 Inv-2 NPTF typ Snap-tite 75	350 bar	570 lpm

Area of use

Grease, Hydraulic oil, Oil

Brand Name

Faster

Corrosion resistance

500 hours salt spray ISO 9227

Material

Steel

Pressure max.

350

Sealing material

NBR, Polyurethane

Surface treatment

Zinc coating (CR III)

Temperature max.

+100

Temperature min.

-25
