Faster CVC

Faster CVC

Select variant
SELECT VARIANT
SELECT VARIANT
Partnumber Description Pressure max. Flow rate nominal LMin Thread inner
CVC080/2215F Skruvkoppling Hona Caterpillar DN12.5 Inv-M22x1.5 340 bar 50 lpm
CVC080/2215M Skruvkoppling Hane Caterpillar DN12.5 Inv-M22x1.5 340 bar 50 lpm
CVC0812GASF Skruvkoppling Hona Caterpillar DN12.5 Inv-G1/2'' 340 bar 50 lpm G 1/2 BSP
CVC0812GASM Skruvkoppling Hane Caterpillar DN12.5 Inv-G1/2'' 340 bar 50 lpm G 1/2 BSP
CVC0858SF Skruvkoppling Hona Caterpillar DN12.5 Inv-UNF7/8'' 340 bar 50 lpm
CVC163/362F Skruvkoppling Hona Caterpillar DN25 Utv-M36x2 25S 340 bar 160 lpm
CVC163/362M Skruvkoppling Hane Caterpillar DN25 Utv-M36x2 25S 340 bar 160 lpm
CVC163015F Skruvkoppling Hona Caterpillar DN25 Inv-M30x1.5 340 bar 160 lpm
CVC163015M Skruvkoppling Hane Caterpillar DN25 Inv-M30x1.5 340 bar 160 lpm
CVC1678SF Skruvkoppling Hona Caterpillar DN25 Inv-UNF1.3/16'' 340 bar 160 lpm
CVC1678SM Skruvkoppling Hane Caterpillar DN25 Inv-UNF1.3/16'' 340 bar 160 lpm
Brand Name
Faster
Corrosion resistance
500 hours salt spray ISO 9227
Material
Steel
Pressure eliminator
No
Pressure max.
340
Sealing material
NBR
Surface treatment
Zinc coating (CR III)
Temperature max.
+125
Temperature min.
-25
