Trailer brake couplings - male

SELECT VARIANT
Partnumber Description Brand Name Size Material Pressure max.
VF1/12GASM Breakaway coupling male VF - DN06 - 1/2"BSP Faster 3/8 " Steel 150 bar
VF1/1615M Snabbkoppling Hane Utv-M16x1.5 ISO5676 Faster 3/8 " Steel 220 bar
VF12GASM Breakaway coupling male VF - DN06 - 1/2"BSP Faster 3/8 " Steel 150 bar
VF18MM Breakaway coupling male VF - DN06 - M18x1.5 (12L) Faster 3/8 " Steel
VF22MM Breakaway coupling male VF - DN06 - M22x1.5 (15L) - bulk Faster 3/8 " Steel 150 bar
VF7/1815MT Snabbkoppling Hane Skotte M18x1.5/12L ISO5676 Faster 3/8 " Steel 220 bar
VF8/2015M Snabbkoppling Hane Skotte M20x1.5/12S ISO5676 3/8 " Steel 220 bar
VF9/1615M Snabbkoppling Hane Skotte M20/M16/10L ISO5676 Faster 3/8 " Steel 220 bar
VF9/1815M Snabbkoppling Hane Skotte M20/M18/12L ISO5676 3/8 " Steel 220 bar
VFF17/38SM Snabbkoppling Hane Skotte ORFS 11/16'' ISO5676 3/8 " Steel 220 bar
Corrosion resistance
500 hours salt spray ISO 9227

Material
Steel

Pressure eliminator
No

Pressure max. connected
150

Sealing material
NBR

Size
3/8

Standard ISO
ISO 5676

Temperature max.
+125

Temperature min.
-25
