VÄXELVENTIL OM G1

Varenummer:

VU2P-1

Pakke str.:

1 st

Min. bestillingsenhed er:

1 st

Specifications
Dimensions and shipping

Brand Name

OM Oleodinamica Marchesini

Dimension H

80 mm

Dimension L

80 mm

Dimension L1

126 mm

Dimension L2

11 mm

Dimension L3

60 mm

Dimension P

1 BSP

Dimension S

50 mm

Dimension U

1 BSP

Dimension ØD

10.5 mm

Flow max.

150 lpm

Flow rate nominal LMin

150 lpm

Material

Steel

Oil Temperature Recommended

50 °C

Oil viscocity recommended

30 cSt

Pressure max.

300 bar

Sealing material

NBR

Surface treatment

Zinc-plated

Temperature max.

+100 °C

Temperature min.

-30 °C

Thread

G 1 BSP

Package size

1 st

Barcode

256057

Gross weight

Net weight

Country of origin

ita

Product information
Measure sketch

VÄXELVENTIL OM G1
