DFE110/12B18ES-W201-12VDC-CVN Walvoil 12 way valve 1/2

Electrically operated directional valve, spool-type from Walvoil.

Partnumber:
DFE110-12-B-12VDC

Package size:
1 st

Min. order quantity is:
1 st
Solenoid D19 24VDC f/DFE20/DFE110
Partnumber: 4SOL519124
Solenoid D19 12VDC f/DFE20/DFE110
Partnumber: 4SOL519112
Brand Name
Walvoil

Contamination level max.
20/18/15 - ISO 4406

Current type
DC

Drainport
G 1/4 BSP

Flow rate nominal LMin
90 lpm

Material
Cast iron

Model
DFE110

Model code
DFE110/12B18ES-W201-12VDC-CVN

Number of ways/positions
12/2

Plug type
DIN EN 175301-803 Form A

Pressure max.
315 bar

Pressure with drain max.
315 bar

Pressure without drain max.
200 bar

Temperature ambient max.
+50 °C

Temperature max.
+80 °C

Temperature min.
-20 °C

Thread
G 1/2 BSP

Voltage
12 V
Package size
1 st

Barcode
240455

Gross weight
9,60 Kg

Net weight
9,60 Kg

Country of origin
ITA

Intrastat code
84812010

Electrically operated directional valve, spool-type from Walvoil.
