HYDRAULSLANG R12 11/4 EN856 SAE100 WP 210 BAR
1 1/4" 31,8x47,5 210bar 240 MSHA
Partnumber:
R12-20
Package size:
120 m
Min. order quantity is:
1 m
Bend radius
240 mm
Brand Name
I.M.M Hydraulics
Diameter inner
31.8 mm
Diameter outer
47.5 mm
Flameresistant
Yes
Hose size
1.1/4 "
Hose type
R12
Hoseapprovals
MSHA
Model code
TFSM012-20
Pressure burst min.
1000 bar
Pressure max.
210 bar
REACH compliant
Yes
RoHs compliant
Yes
Standard EN
EN 856 R12
Standard ISO
ISO 3862 R12
Standard SAE
SAE 100R12
Temperature intermittent max.
+125 °C
Temperature max.
+120 °C
Temperature min.
-40 °C
Package size
120 m
Barcode
220062
Gross weight
Kg
Net weight
Kg
Country of origin
ita
1 1/4" 31,8x47,5 210bar 240 MSHA
Crimp dimensions R12-20
|
Hose type |
Diamter - inch |
Hose coupling type |
Ferrule |
Crimp dimension - mm |
Skiving - int. |
Skiving - ext. |
Operating pressure |
|---|---|---|---|---|---|---|---|
| R12-20 | 1.1/4 | PS20 | 9P4010-20R12 |
50.1 mm
0.0
0.2 |
No |
54.0 mm
±
|
210 |
