OMM 50 HYDRAULIC MOTOR
OMM and OML are ideal for use in industrial applications as well as the mobile sector, eg. mobile conveyors for agricultural machinery.
Partnumber:
151G0037
Package size:
1 st
Min. order quantity is:
1 st
Brand Name
White
C
M6
Continuous power max.
2.4 kW
Continuous rotation max.
400 rpm
D
G 3/8 BSP
Displacement
50.3 cm3
Drainport
G 1/8 BSP
E
G 1/8 BSP
Holes circle
45 mm
Intermittent Rotation speed Max.
500
Intermittent Torque Max.
88 Nm
L
122 mm
L1
21,5 mm
Mounting flange
OMM 45
Number of mounting holes
3
Oil viscocity recommended
20 - 75 cSt
Port position
Rear
Power max.
3.2 kW
Pressure continous max.
140 bar
Pressure drop continuous max.
70 bar
Pressure intermittent max.
175 bar
Pressure peak max.
225 bar
Recess
31,5 mm
Rotational speed max.
500 rpm
Sealing material
NBR
Shaft diameter
16 mm
Shaft keyway
5,0 mm
Shaft spline
DIN 6885
Shaft type
Cylindrical
Torque continuous max.
46 Nm
Torque output max.
88 Nm
Working ports
G 3/8 BSP
Package size
1 st
Barcode
333755
Gross weight
2,33 Kg
Net weight
2,33 Kg
Country of origin
Intrastat code
84122981
OMM and OML are ideal for use in industrial applications as well as the mobile sector, eg. mobile conveyors for agricultural machinery.
