OMS 400 HYDRAULIC MOTOR Series 3
Orbit motor for more difficult working conditions in many applications. Output shaft with tapered roller bearings provides high static and dynamic bearing capacity. Orbit set with rollers and separate integrated valve. High volumetric and mechanical efficiency. Long durability at high pressures.
Artikelnummer:
151F0605
Förpackningsstorlek:
1 st
Minsta beställningskvantitet:
1 st
A
M22x1,5
Brand Name
White
C
G 1/4 BSP
Continuous power max.
11 kW
Continuous rotation max.
190 rpm
D
M10
Displacement
393 cm3
Drainport
G 1/4 BSP
E
G 1/2 BSP
Holes circle
106.4 mm
Intermittent Effect Max.
12.5
Intermittent Rotation speed Max.
230
Intermittent Torque Max.
990 Nm
L
221 mm
L1
68,4 mm
L2
178 mm
L3
67 mm
Mounting flange
Square 82,5
Number of mounting holes
4
Oil viscocity recommended
20 - 75 cSt
Port position
Side
Power max.
11 kW
Pressure continous max.
140 bar
Pressure drop continuous max.
160 bar
Pressure intermittent max.
175 bar
Pressure peak max.
210 bar
Recess
82,5 mm
Rotational speed max.
190 rpm
Shaft diameter
32 mm
Shaft keyway
10,0 mm
Shaft type
Cylindrical
Torque continuous max.
865 Nm
Torque output max.
990 Nm
Working ports
G 1/2 BSP
X
32 mm
Pakke str.
1 st
Stregkode
333749
Brutto vægt
13,85 Kg
Netto vægt
13,85 Kg
Oprindelsesland
Intrastat varekode
84122981
Orbit motor for more difficult working conditions in many applications. Output shaft with tapered roller bearings provides high static and dynamic bearing capacity. Orbit set with rollers and separate integrated valve. High volumetric and mechanical efficiency. Long durability at high pressures.
