TFSM012 hydraulic hoses

TFSM012 hydraulic hoses

Select variant
SELECT VARIANT
SELECT VARIANT
Partnumber Description Hose size Pressure max. Hose type Bend radius
R12-16 Hydraulslang R12 1'', EN856 SAE100 WP 280 bar 1 " R12
R12-20 HYDRAULSLANG R12 11/4 EN856 SAE100 WP 210 BAR 1.1/4 " 210 bar R12 240 mm
Brand Name
I.M.M Hydraulics
Flameresistant
Yes
Hose type
R12
Hoseapprovals
MSHA
REACH compliant
Yes
RoHs compliant
Yes
Standard EN
EN 856 R12
Standard ISO
ISO 3862 R12
Standard SAE
SAE 100R12
Temperature intermittent max.
+125
Temperature max.
+120
Temperature min.
-40
