High pressure air hose 1.1/2" Yellow 20 Bar

High pressure air hose 1.1/2" Yellow 20 Bar

Select variant
SELECT VARIANT
SELECT VARIANT
Partnumber Description Diameter inner Pressure max. Pressure burst min. Bend radius
EHA501-08 High pressure air hose 1/2" Yellow 20 Bar 12.7 mm 20 bar 64 bar 65 mm
EHA501-12 High pressure air hose 3/4" Yellow 20 Bar 19 mm 20 bar 64 bar 95 mm
EHA501-16 High pressure air hose 1" Yellow 20 Bar 25.4 mm 20 bar 64 bar 125 mm
EHA501-20 High pressure air hose 1.1/4" Yellow 20 Bar 32 mm 20 bar 64 bar 300 mm
EHA501-24 High pressure air hose 1.1/2" Yellow 20 Bar 38 mm 20 bar 64 bar 360 mm
EHA501-32 High pressure air hose 2" Yellow 20 Bar 50.8 mm 20 bar 64 bar 450 mm
EHA501-40 High pressure air hose 2.1/2" Yellow 20 Bar 63.5 mm 20 bar 64 bar 600 mm
EHA501-48 High pressure air hose 3" Yellow 20 Bar 76.2 mm 20 bar 64 bar 750 mm
EHA501-64 High pressure air hose 4" Yellow 20 Bar 101.6 mm 20 bar 64 bar 1000 mm
Area of use
Compressed air, Neutral or aggressive gases and liquids, Water
Brand Name
Danfoss
Color
Yellow
Cover
SBR based
Field of application
Air
Hoseapprovals
2016 Type 2 Class A, TS 745-ENISO 2398 Type 4
Length
61
Pressure burst min.
64
Pressure max.
20
Reinforcement
Synthetic fiber
Temperature max.
+70
Temperature min.
-25
