Claw coupling male thread, stainless, DIN 3489, type EKA

Claw coupling male thread, stainless, DIN 3489, type EKA

Select variant
SELECT VARIANT
SELECT VARIANT
Partnumber Description Pressure max. Spigot distance Thread
201G-1-SY Claw Coupling male BSP stainless steel dim. 1" (25mm) EKA10V 16 bar 42 mm G 1 BSP
201G-1/2-SY Claw Coupling male BSP stainless steel dim. 1/2" (13mm) EKA1 16 bar 42 mm G 1/2 BSP
201G-3/4-SY Claw Coupling male BSP stainless steel dim. 3/4" (19mm) EKA3 16 bar 42 mm G 3/4 BSP
Brand Name
Ludecke
Material
Stainless steel
Material quality
1.4404 / AISI316L
Pressure max.
16
Sealing material
FKM/FPM (Viton®)
Spigot distance
42
Standard DIN
DIN 3489
Temperature max.
+200
Temperature min.
-30
Thread ISO standard
ISO 228
