Check valves Faster - VU-F

BACKVENTIL INV/INV 11/2 200BAR

Backventil, Inv G1/2'', 350Bar, Qn=90L/MIN, 0.35Bar

BACKVENTIL INV G1/4 500BAR

Backventil, Inv G1, 250Bar,Qn=200L/MIN, 0.35Bar, L=100mm

BACKVENTIL INV G3/4 250BAR

BACKVENTIL INV G3/8 350BAR

SELECT VARIANT

Partnumber	Description	Thread	Pressure opening	Flow rate nominal LMin	Pressure max.
VU112F112F	BACKVENTIL INV/INV 11/2 200BAR	G 1.1/2 BSP	0.35 bar	500 lpm	200 bar
VU12F12F	Backventil, Inv G1/2'', 350Bar, Qn=90L/MIN, 0.35Bar	G 1/2 BSP	0.35 bar	90 lpm	350 bar
VU14F14F	BACKVENTIL INV G1/4 500BAR	G 1/4 BSP	0.35 bar	17 lpm	500 bar
VU1F1F	Backventil, Inv G1, 250Bar,Qn=200L/MIN, 0.35Bar, L=100mm	G 1 BSP	0.35 bar	200 lpm	250 bar
VU34F34F	BACKVENTIL INV G3/4 250BAR	G 3/4 BSP	0.35 bar	140 lpm	250 bar
VU38F38F	BACKVENTIL INV G3/8 350BAR	G 3/8 BSP	0.35 bar	68 lpm	350 bar

Material

Steel

Pressure opening

0.35

Sealing material

NBR

Temperature max.

+125

Temperature min.

-25
