JGEN-03-02
|
Adapter Rak, Utv-JIC, Utv-NPT |
|
3/8-24 JIC |
1/8 NPT |
|
|
JGEN-03-04
|
Adapter Rak, Utv-JIC, Utv-NPT |
|
3/8-24 JIC |
1/4 NPT |
|
|
|
JGEN-04-02
|
S200-06-10N adaptor NPT |
6 mm |
7/16-20 JIC |
1/8 NPT |
450 bar |
|
|
JGEN-04-04
|
Adapter Rak, Utv-JIC, Utv-NPT |
6 mm |
7/16-20 JIC |
1/4 NPT |
350 bar |
|
JGEN-04-06
|
Adapter Rak, Utv-JIC, Utv-NPT |
6 mm |
7/16-20 JIC |
3/8 NPT |
350 bar |
|
|
JGEN-04-08
|
Adapter Rak, Utv-JIC, Utv-NPT |
6 mm |
7/16-20 JIC |
1/2 NPT |
350 bar |
|
JGEN-05-02
|
Adapter Rak, Utv-JIC, Utv-NPT |
8 mm |
1/2-20 JIC |
1/8 NPT |
|
|
|
JGEN-05-04
|
Adapter Rak, Utv-JIC, Utv-NPT |
8 mm |
1/2-20 JIC |
1/4 NPT |
|
|
|
JGEN-05-06
|
Adapter Rak, Utv-JIC, Utv-NPT |
8 mm |
1/2-20 JIC |
3/8 NPT |
|
|
|
JGEN-06-02
|
Adapter Rak, Utv-JIC, Utv-NPT |
10 mm |
9/16-18 JIC |
1/8 NPT |
350 bar |
|
|
JGEN-06-04
|
Adapter Rak, Utv-JIC, Utv-NPT |
10 mm |
9/16-18 JIC |
1/4 NPT |
350 bar |
|
|
JGEN-06-06
|
Adapter Rak, Utv-JIC, Utv-NPT |
10 mm |
9/16-18 JIC |
3/8 NPT |
350 bar |
|
|
JGEN-06-08
|
Adapter Rak, Utv-JIC, Utv-NPT |
10 mm |
9/16-18 JIC |
1/2 NPT |
350 bar |
|
|
JGEN-08-04
|
Adapter Rak, Utv-JIC, Utv-NPT |
12 mm |
3/4-16 JIC |
1/4 NPT |
350 bar |
|
|
JGEN-08-06
|
Adapter Rak, Utv-JIC, Utv-NPT |
12 mm |
3/4-16 JIC |
3/8 NPT |
350 bar |
|
JGEN-08-08
|
Adapter Rak, Utv-JIC, Utv-NPT |
12 mm |
3/4-16 JIC |
1/2 NPT |
350 bar |
|
|
JGEN-08-12
|
Adapter Rak, Utv-JIC, Utv-NPT |
12 mm |
3/4-16 JIC |
3/4 NPT |
350 bar |
|
|
JGEN-10-04
|
Adapter Rak, Utv-JIC, Utv-NPT |
16 mm |
7/8-14 JIC |
1/4 NPT |
|
|
|
JGEN-10-06
|
Adapter Rak, Utv-JIC, Utv-NPT |
16 mm |
7/8-14 JIC |
3/8 NPT |
350 bar |
|
|
JGEN-10-08
|
Adapter Rak, Utv-JIC, Utv-NPT |
16 mm |
7/8-14 JIC |
1/2 NPT |
350 bar |
|
|
JGEN-10-12
|
Adapter Rak, Utv-JIC, Utv-NPT |
16 mm |
7/8-14 JIC |
3/4 NPT |
350 bar |
|
|
JGEN-12-08
|
Adapter Rak, Utv-JIC, Utv-NPT |
18-20 mm |
1.1/16-12 JIC |
1/2 NPT |
350 bar |
|
|
JGEN-12-12
|
Adapter Rak, Utv-JIC, Utv-NPT |
18-20 mm |
1.1/16-12 JIC |
3/4 NPT |
350 bar |
|
|
JGEN-12-16
|
Adapter Rak, Utv-JIC, Utv-NPT |
20 mm |
1.1/16-12 JIC |
1 NPT |
350 bar |
|
|
JGEN-16-08
|
Adapter Rak, Utv-JIC, Utv-NPT |
20 mm |
1.5/16-12 JIC |
1/2 NPT |
280 bar |
|
|
JGEN-16-12
|
SJN2112 |
20 mm |
1.5/16-12 JIC |
3/4 NPT |
280 bar |
|
|
JGEN-16-16
|
Adapter Rak, Utv-JIC, Utv-NPT |
25 mm |
1.5/16-12 JIC |
1 NPT |
|
|
|
JGEN-16-20
|
Adapter Rak, Utv-JIC, Utv-NPT |
20 mm |
1.5/16-12 JIC |
1.1/4 NPT |
|
|
|
JGEN-20-16
|
Adapter Rak, Utv-JIC, Utv-NPT |
25 mm |
1.5/8-12 JIC |
1 NPT |
|
|
|
JGEN-20-20
|
Adapter Rak, Utv-JIC, Utv-NPT |
30-32 mm |
1.5/8-12 JIC |
1.1/4 NPT |
210 bar |
|
|
JGEN-20-24
|
Adapter Rak, Utv-JIC, Utv-NPT |
25 mm |
1.5/8-12 JIC |
1.1/2 NPT |
|
|
|
JGEN-24-20
|
Adapter Rak, Utv-JIC, Utv-NPT |
32 mm |
1.7/8-12 JIC |
1.1/4 NPT |
140 bar |
|
|
JGEN-24-24
|
Adapter Rak, Utv-JIC, Utv-NPT |
32 mm |
1.7/8-12 JIC |
1.1/2 NPT |
140 bar |
|
|
JGEN-32-32
|
Adapter Rak, Utv-JIC, Utv-NPT |
|
2.1/2-12 JIC |
2 NPT |
|
