Skottgenomgång Ø12 mm
The XVR series of acid-resistant push-in nipples are suitable for use in aggressive environments and critical installations. Suitable for use with food and clean water.
Artikelnummer:
SXMM-1200
Förpackningsstorlek:
2 st
Minsta beställningskvantitet:
1 st
Angle
0 °
Area of use
Compressed air, Gas and liquids compatible with constituent materials, Vacuum
Brand Name
Tierre
Diameter pipe
12 mm
Material
Stainless steel
Material quality
AISI 316L
Model code
XVRMM12
Pressure max.
20 bar
REACH compliant
Yes
RoHs compliant
Yes
Sealing material
FKM/FPM (Viton®), PVDF-UHM
Standard
Silicone Free
Standard EN
DM 174/2004, EC 1935/2004, ICIM Food, ICIM Water
Standard SAE
NSF/ANSI 169
Temperature max.
+150 °C
Temperature min.
-20 °C
Vacuum max.
-0.95 bar
Package size
2 st
Barcode
309991
Gross weight
Kg
Net weight
Kg
Country of origin
ita
The XVR series of acid-resistant push-in nipples are suitable for use in aggressive environments and critical installations. Suitable for use with food and clean water.
