Digital pressure gauge 0 - 5 bar +/-0,5% accuracy
Digital manometer with digital readout and high degree of accuracy (0.5% FS). Continuously measures working pressure and records minimum and maximum pressure Optional readout in: Bar, PSI, Mpa, kPa, mbar.
Partnumber:
SPG-DIGI-B0005-B
Package size:
1 pcs
Min. order quantity is:
1 pcs
BatteryType
2 x 1.5 V DC AA (LR6-AA)
Brand Name
Stauff
Diameter
90 mm
Field of application
Lubricants, Oil, Water
Height
127.61 mm
Humidity
< 85%
Material
Housing: die-cast zinc with TPE, Wetted parts: stainless steel and ceramics
Model code
SPG-DIGI-B0005-B
Port position
Side
Pressure burst min.
50 bar
Pressure measurement accuracy
±0,5% FS
Pressure peak max.
30 bar
Pressure setting max.
5 bar
Pressure setting min.
-1 bar
Protection class
IP 65
Sealing material
NBR
Temperature ambient max.
+50 °C
Temperature ambient min.
-10 °C
Temperature max.
+80 °C
Temperature min.
-20 °C
Temperature storage max.
+60
Temperature storage min.
-20
Thread
G 1/4 BSP
Vibration and shock
IEC 60068-2-6 (5 g) / IEC 60068-2-27 (25 g) 11ms
Width
44 mm
Package size
1 pcs
Barcode
442940
Gross weight
Kg
Net weight
0,485 Kg
Country of origin
deu
Intrastat code
90262040
Digital manometer with digital readout and high degree of accuracy (0.5% FS). Continuously measures working pressure and records minimum and maximum pressure Optional readout in: Bar, PSI, Mpa, kPa, mbar.
Note: Opening 3D files requires a program that supports the file format
