Screw coupling male HS - DN19 - M30x2 (20S)
Standard DIN-coupling often used on mobile-cranes and within industry.
Can be connected by hand up till an approx. pressure of 50 bar.
Varenummer:
HS12-2-S2030
Pakke str.:
1 st
Min. bestillingsenhed er:
1 st
Brand Name
Stauff
Diameter pipe
20 mm
Dimension C
63 mm
Dimension E metric
M30x2
Dimension H
48 mm
Dimension L2
74 mm
Dimension SW
36, 41 mm
Flow rate nominal LMin
120 lpm
ISO size
19
Material
Steel
Model code
QRC-HS-19-M-20S-B-W66
Pressure max.
400 bar
Sealing material
NBR
Series
S
Size
3/4 "
Standard ISO
ISO 14541
Surface treatment
Zinc coating (CR III)
Temperature max.
+100 °C
Temperature min.
-25 °C
Thread outer metric
M30x2
Package size
1 st
Barcode
356861
Gross weight
0,41 Kg
Net weight
0,41 Kg
Country of origin
DEU
Intrastat code
84812010
Standard DIN-coupling often used on mobile-cranes and within industry.
Can be connected by hand up till an approx. pressure of 50 bar.
