Screw coupling female HS - DN12,5 - 1/2" BSP female
Screw coupling female HS - DN12,5 - 1/2" BSP female
Varenummer:
HS10-1-IGF08
Pakke str.:
1 pcs
Min. bestillingsenhed er:
1 pcs
Om du beställer denna artikel så kommer
HSN-12-F-G08
bli beställd istället.
A
G 1/2 BSP
Brand Name
Stauff
Connection
Screw
Disconnection
Screw
Field of application
Construction Machinery
Flowrate nominal LMin
80 lpm
ISO size
12.5
L1
67 mm
Material
Steel
Pressure burst min.
1200 bar
Pressure max.
400 bar
Pressurized connection
Male Tip/Female Body up to 33% of the Working Pressure with Tools
SW
30 mm
Sealing material
NBR
Size
1/2 "
Spillage
3,1 ml
Standard ISO
ISO 14541
Surface treatment
Zinc coating (CR III)
Temperature max.
+100 °C
Temperature min.
-25 °C
Thread DIN standard
DIN 3852-2-A
Thread ISO standard
ISO 9974-1
Thread outer metric
M36x2
Förpackningsstorlek
1 pcs
Streckkod
356776
Bruttovikt
0,27 Kg
Nettovikt
0,27 Kg
Ursprungsland
DEU
Intrastat artikelkod
84812010
Screw coupling female HS - DN12,5 - 1/2" BSP female
