DB C.B Val. 60l/m 80-230bar 4.5:1 1/2" DCB10-AV-3-B-1-E-100-
It is preferable to place the valve as close to the actuator as possible, preferably directly on the actuator with fixed connections. This provides maximum protection in case of hose breaks and the like
Partnumber:
11104591
Package size:
1 st
Min. order quantity is:
1 st
Brand Name
Danfoss
Contamination level max.
20/18/14 - ISO 4406
Flow rate nominal LMin
60 lpm
Material
Steel
Model code
DCB10-AV-3-B-1-E-100-B-SES4B
Oil viscocity recommended
12 - 54 cSt
Pilot ratio
4,5:1
Pressure max.
350 bar
Pressure setting max.
350 bar
Pressure setting min.
90 bar
Thread
G 1/2 BSP
Pakke str.
1 st
Stregkode
374663
Brutto vægt
1,14 Kg
Netto vægt
1,14 Kg
Oprindelsesland
ITA
Intrastat varekode
84812010
It is preferable to place the valve as close to the actuator as possible, preferably directly on the actuator with fixed connections. This provides maximum protection in case of hose breaks and the like
