3/2 manually operated valves MW

SELECT VARIANT

Partnumber	Description	Thread	Number of ways/positions	Pressure max.	Pressure min.
MAV23BRENC	PI-venttiili 70 Manual MAV	G 1/8 BSP	3/2	10 bar	2.5 bar
MAV23LEB00	PI-venttiili 70 Manual MAV	G 1/8 BSP	3/2	10 bar	-0.99 bar
MAV23LESNC	PI-venttiili 70 Manual MAV	G 1/8 BSP	3/2	10 bar	-0.99 bar
MAV23PPSNC	PI-venttiili 70 Manual MAV	G 1/8 BSP	3/2	10 bar	-0.99 bar
MAV23VLBOO	Pneumatic valve 70 Manual MAV	G 1/8 BSP	3/2	10 bar	-0.99 bar
MAV33LEB00	PI-venttiili 70 Manual MAV	G 1/4 BSP	3/2	10 bar	-0.99 bar
MAV33LESNC	PI-venttiili 70 Manual MAV	G 1/4 BSP	3/2	10 bar	-0.99 bar
MAV43LESNC	PI-venttiili 70 Manual MAV	G 1/2 BSP	3/2	10 bar	-0.99 bar

Brand Name

Metal Work

Lever

Inclusive

Material

Aluminium

Number of ways/positions

3/2

Pressure max.

REACH compliant

Yes

RoHs compliant

Yes

Sealing material

NBR

Temperature max.

+60

Temperature min.

-10
