Orbital motors M+S RW series

RW100KB

Hydraulimoottori, 125,7cm³/r

Motor M+S 200cc, Kon 1:10

RW315KB

Motor M+S 400cc cyl32

SELECT VARIANT

Partnumber	Description	Displacement	Shaft diameter	Shaft type	Continuous power max.
RW100KB	RW100KB	99.8 cm3	35 mm	Tapered	13 kW
RW125KBUKPC	Hydraulimoottori, 125,7cm³/r	125.7 cm3	35 mm	Tapered	12.5 kW
RW200KB	Motor M+S 200cc, Kon 1:10	199.8 cm3	35 mm	Tapered	11 kW
RW315KB	RW315KB	315.7 cm3	35 mm	Tapered	9 kW
RW400CB	Motor M+S 400cc cyl32	397 cm3	32 mm	Cylindrical	7.8 kW

Brand Name

Hydraspecma

Contamination level max.

-/20/16 - ISO 4406

Drainport

G 1/4

Filtration degree

Holes circle

147.6

Mounting flange

N/A

Number of mounting holes

Oil viscocity recommended

20 - 75

Port position

Side

Recess

82,5

Temperature max.

+82

Temperature min.

-40

Working ports

G 1/2
