Bulkhead adapter 90° elbow JIC x JIC

SELECT VARIANT

Partnumber	Description	Diameter pipe	Thread outer	Pressure max.	Brand Name
S650-04	S650-06U bulkhead elbow	6 mm	7/16-20 JIC	450 bar
S650-04-FOR	S650-06U bulkhead elbow	6 mm	7/16-20 JIC	450 bar	FOR
S650-05	S650-08U bulkhead elbow	8 mm	1/2-20 JIC	416 bar	FOR
S650-06	S650-10U bulkhead elbow	10 mm	9/16-18 JIC	350 bar	FOR
S650-08	S650-12U bulkhead elbow	12 mm	3/4-16 JIC	350 bar
S650-08-FOR	S650-12U bulkhead elbow	12 mm	3/4-16 JIC	350 bar	FOR
S650-10	S650-16U bulkhead elbow	16 mm	7/8-14 JIC	350 bar	FOR
S650-12	S650-20U bulkhead elbow	20 mm	1.1/16-12 JIC	320 bar	FOR
S650-16	Läpivientiliitin 90° uk-uk	25 mm	1.5/16-12 JIC	280 bar	Hydraspecma
S650-16-FOR	S650-25U bulkhead elbow	25 mm	1.5/16-12 JIC	290 bar	FOR
S650-20	S650-30U bulkhead elbow		1.5/8-12 JIC		Hydraspecma
S650-20-FOR	S650-30U bulkhead elbow	30 mm	1.5/8-12 JIC	250 bar	FOR
S650-24	SKOTTADAPTER 90K UTV-JIC	38 mm	1.7/8-12 JIC	140 bar	Hydraspecma
S650-24-FOR	S650-38U bulkhead elbow	38 mm	1.7/8-12 JIC	250 bar	FOR

Angle
