NG06 valves Duplomatic 4/2

NG06 valves Duplomatic 4/2

Select variant
SELECT VARIANT
SELECT VARIANT
Partnumber Description Pressure T max. Current type Number of ways/positions Voltage
DS3-SA1/11N-A230K1 4/2-suuntaventtiili NS6 160 bar AC 4/2 230 V
DS3-SB2/11N-A230K1 4/2-suuntaventtiili NS6 160 bar AC 4/2 230 V
DS3-TA/11N-A230K1 4/2-suuntaventtiili NS6 160 bar AC 4/2 230 V
DS3B-SA1/11N-SD12K1 4/2-suuntaventtiili NS6 250 bar DC 4/2 12 V
DS3B-SA1/11N-SD24K1 4/2-suuntaventtiili NS6 250 bar DC 4/2 24 V
DS3B-SB2/11N-SD12K1 4/2-suuntaventtiili NS6 250 bar DC 4/2 12 V
DS3B-SB2/11N-SD24K1 4/2-suuntaventtiili NS6 250 bar DC 4/2 24 V
DS3B-SB3/11N-SD24K1 Solenoid actuated directional valve direct operated 250 bar DC 4/2 24 V
DS3B-TA/11N-SD12K1 4/2-suuntaventtiili NS6 250 bar DC 4/2 12 V
DS3B-TA/11N-SD24K1 4/2-suuntaventtiili NS6 250 bar DC 4/2 24 V
DS3B-TB/11N-SD24K1 Solenoid actuated directional valve direct operated 250 bar DC 4/2 24 V
Activation
Solenoid
Brand Name
Duplomatic
Contamination level max.
20/18/15 - ISO 4406
NG ISO-size
NG06
Number of ways/positions
4/2
Oil viscocity recommended
25
Plug type
DIN 43650 Form A, DIN EN 175301-803 Form A
Protection class
IP 65
Surface treatment
Phosphated (black)
Temperature max.
+80
Temperature min.
-20
Torque tightening
5
