6 way diverter valves electrical DFE 6/2

SELECT VARIANT

Partnumber	Description	Flow rate nominal LMin	Voltage
DFE052/6A18ESCW201-12	DFE052/6A18ESC-W201-12VDC-CRZ
DFE052/6A18ESCW201-24	DFE052/6A18ESC-W-201-24Vdc <CRZ> 6/2 valve 3/8"	60 lpm	24 V
DFE052/6B18ESC-W201-12	DFE052/6B18ESC-W201-12VDC <CRZ>	60 lpm	12 V
DFE052/6B18ESCW201-24	DFE052/6B18ESC-W201-24VDC-CRZ
DFE052/6B18ESW201-24	DFE052/6B18ES-W-201-24Vdc <CRZ> Walvoil 6/2 way valve 3/8	60 lpm	24 V
DFE080/6A18ESW20012V	DFE080/6A18ES-W-201-12VDC Walvoil 6/2-way valve 1/4	25 lpm	12 V
DFE10/6A18ES24V	6/2 suuntaventtiili 24VDC R1/2"	90 lpm	24 V
DFE102/6A18ESW202-12	DFE102/6A18ES-W202-12VDC-CRZ Walvoil 6/2-way valve 1/2" open	90 lpm	12 V
DFE102/6A18ESW202-24	DFE102/6A18ES-W202-24VDC-CRZ Walvoil 6/2-way valve 1/2" open	90 lpm	24 V
DFE102/6B18ESW202-12	DFE102/6B18ES-W202-12VDC-CRZ Walvoil 6/2-way valve 1/2"	90 lpm	12 V
DFE102/6B18ESW20224VDCCRZ	DFE102/6B18ES-W202-24VDC-CRZ Walvoil 6/2-way valve 1/2"	90 lpm	24 V
DFE140/6B18ESCW12VCRZ	6/2 diverter valve DFE140/6B18ESC-W201-12VDC-CRZ	80 lpm	12 V
DFE20/6A18ESCW201-12	DFE20/6A18ESC-W201-12VDC-CRZ Walvoil 6/2 way valve 3/4	140 lpm	12 V
DFE20/6A18ESCW201-24	DFE20/6A18ESC-W201-24VDC-CRZ Walvoil 6/2 way valve 3/4	140 lpm	24 V
DFE20/6B18ESCW201-12	DFE20/6B18ESC-W201-12VDC-CRZ
DFE20/6B18ESCW201-24	DFE20/6B18ESC-W201-24VDC-CRZ

Activation

Solenoid

Brand Name

Walvoil

Contamination level max.

20/18/15 - ISO 4406

Drainport

G 1/4

Number of ways/positions

6/2

Oil viscocity recommended

12 - 400

Pressure with drain max.

315

Pressure without drain max.

200

Protection class

IP 65

Temperature min.

-20
