Y-Lähtöliitin R23/M G 1/4"uk - 8mm putkelle
G 1/4"uk - 8mm putkelle
Partnumber:
R23M0804
Package size:
1 kpl
Min. order quantity is:
1 kpl
Area of use
Compressed air, Vacuum
Brand Name
Metal Work
CH
14 mm
Diameter pipe
8 mm
E
18 mm
F
G 1/4 BSP
F1
3,3 mm
I
15,8 mm
L
52,8 mm
L1
7,2 mm
L2
28,2 mm
Material
Brass, Technopolymer
Model code
2L23410
P
8 mm
Pressure max.
12 bar
REACH compliant
Yes
RoHs compliant
Yes
Sealing material
NBR
Temperature max.
+60 °C
Temperature min.
-20 °C
Thread
G 1/4 BSP
Thread outer
G 1/4 BSP
Vacuum max.
0.99 bar
Ø
8 mm
Package size
1 kpl
Barcode
484906
Gross weight
0,025 Kg
Net weight
0,025 Kg
Country of origin
IT
G 1/4"uk - 8mm putkelle
Note: Opening 3D files requires a program that supports the file format
