QTM3-D/10N/S Flow control and Check valve A+B Cetop 3
QTM3-D/10N/S Flow control and Check valve A+B Cetop 3 350bar 50l/min meter out
Partnumber:
QTM3-D/10N/S
Package size:
1 pcs
Min. order quantity is:
1 pcs
Brand Name
Duplomatic
Contamination level max.
20/18/15 - ISO 4406
Flow rate nominal LMin
50, 75 lpm
Material
Steel
Model code
QTM3-D/10N/S
NG ISO-size
NG06
Oil viscocity recommended
25 cSt
Pressure compensated
No
Pressure max.
350 bar
Sealing material
NBR
Surface treatment
Phosphated (black)
Temperature max.
+80 °C
Temperature min.
-20 °C
Valve type
Throttle/checkvalve
Package size
1 pcs
Barcode
468362
Gross weight
Kg
Net weight
1,40 Kg
Country of origin
ita
Intrastat code
84812010
QTM3-D/10N/S Flow control and Check valve A+B Cetop 3 350bar 50l/min meter out
