Q25M/1-F1S-103/A1/D41/24V-F3D
1-section Q25 monoblock directional valve with built-in pressure relief valve. Manually and solenoid activated.
Spool function: Double acting with port A and B closed in neutral position. Spring centered.
Open center port P to T in neutral position.
Partnumber:
Q25/1X03D-24V
Package size:
1 kpl
Min. order quantity is:
1 kpl
Activation
Manual, Solenoid
Brand Name
Walvoil
Contamination level max.
16/14/12 - ISO 4406
Current type
DC
Dimension F
107 mm
E
76 mm
Flow rate nominal LMin
30 lpm
Lever
Exclusive
Material
Cast iron
Model code
Q25M/1-F1S-103/A1/D41/24V-F3D
Number of sections
1
Oil viscocity recommended
10 - 400 cSt
Port P1
G 3/8 BSP
Port P2
G 3/8 BSP
Port T
G 1/2 BSP
Port T1
G 3/8 BSP
Pressure T max.
25 bar
Pressure carry-over
No
Pressure max.
300 bar
Pressure relief valve
Yes
Pressure setting max.
200 bar
Pressure setting min.
100 bar
Temperature max.
+80 °C
Temperature min.
-30 °C
Voltage
24 V
Working ports
G 3/8 BSP
Package size
1 kpl
Barcode
432891
Gross weight
4,26 Kg
Net weight
4,26 Kg
Country of origin
ITA
Intrastat code
84812010
1-section Q25 monoblock directional valve with built-in pressure relief valve. Manually and solenoid activated.
Spool function: Double acting with port A and B closed in neutral position. Spring centered.
Open center port P to T in neutral position.
