MRE250SHU
Partnumber:
MRE250SHU
Package size:
1 kpl
Min. order quantity is:
1 kpl
Brand Name
Hydraspecma
C
4xM8
Comment
High pressure seal
Contamination level max.
-/20/16 - ISO 4406
Continuous power max.
8 kW
Continuous rotation max.
240 rpm
Displacement
250.1 cm3
Drainport
G 1/4 BSP
Filtration degree
25 my
Holes circle
106.4 mm
Intermittent Effect Max.
9.5 kW
Intermittent Rotation speed Max.
300 rpm
Intermittent Torque Max.
470 Nm
L
192 mm
L1
43.5 mm
Mounting flange
SAE-A2
Number of mounting holes
2
Number of outer grooves
6
Oil viscocity recommended
20 - 75 cSt
P
G 1/2 BSP
Port position
Rear
Pressure continous max.
175 bar
Pressure drop continuous max.
110 bar
Pressure intermittent max.
200 bar
Recess
82,5 mm
Shaft diameter
25,4 mm
Shaft spline
SAE 6B 1"
Shaft torque rating
400 Nm
Shaft type
Spline
T
G 1/4 BSP
Temperature max.
+82 °C
Temperature min.
-40 °C
Torque continuous max.
390 Nm
Working ports
G 1/2 BSP
Package size
1 kpl
Barcode
401542
Gross weight
8,40 Kg
Net weight
8,40 Kg
Country of origin
BG
