MPW 250 CD
Partnumber:
MPW250CD
Package size:
1 kpl
Min. order quantity is:
1 kpl
Brand Name
Hydraspecma
Contamination level max.
18/16/13 - ISO 4406
Continuous power max.
7.5 kW
Continuous rotation max.
242 rpm
Displacement
247.5 cm3
Drainport
G 1/4 BSP
Filtration degree
25 my
Holes circle
103 mm
Intermittent Effect Max.
12 kW
Intermittent Rotation speed Max.
303 rpm
Intermittent Torque Max.
583 Nm
L
105 mm
L1
33.33 mm
Mounting flange
Wheel mount
Number of mounting holes
4
Oil viscocity recommended
20 - 75 cSt
P
G 1/2 BSP
Port position
Side
Pressure continous max.
175 bar
Pressure drop continuous max.
110 bar
Pressure intermittent max.
200 bar
Recess
80,0 mm
Rotational speed min.
10 rpm
Shaft diameter
25 mm
Shaft keyway
8,0 mm
Shaft torque rating
340 Nm
Shaft type
Cylindrical
T
G 1/4 BSP
Temperature max.
+82 °C
Temperature min.
-40 °C
Torque continuous max.
380 Nm
Working ports
G 1/2 BSP
Package size
1 kpl
Barcode
401484
Gross weight
6,20 Kg
Net weight
6,20 Kg
Country of origin
BG
