S191-1 1/2" (8090-24-24) DN40 KULVENTIL LÅGTRYCK
Ball valve in nickel-plated brass
with full flow for non-corrosive media such as water, compressed air, oils and petroleum.
Thread ISO 7/1 UNI-EN 10226
Temperature -20°C to +140°C
From PN80 (1/4") to PN16 (4)
Housing in brass CW617N UNI-EN 12165
Ball in chrome-plated brass CW614N UNI-EN 12164
Seat and other seals in PTFE
Handle in plastic-coated aluminum AL UNI5076
Osanumero:
K60-24N/N-LOGIC
Pakkauskoko:
1 pcs
Pienin tilausmäärä on:
1 pcs
Aktivointityyppi
Manual
Kierre
G 1.1/2 BSP
Kierre EN standardi
EN 10226-1
Kierre muoto
Female x female
Laatu
CW614N/CW617N
Lämpötila max.
+140 °C
Lämpötila min.
-20 °C
Mallikoodi
S0191N38
Materiaali
Brass
Paine max.
63 bar
Pinta
Nickel-plated
Portit/asennot
2/2
Soveltamisala
Air, Diesel, Gasoline, Grease, Hydraulic oil, Water
Standardi EN
EN 13828
Tiivistysmateriaali
PTFE (Teflon®)
Tuotemerkit
Enolgas
Vipu
Inclusive
Vivun tyyppi
Angled
Package size
1 pcs
Barcode
497608
Gross weight
1,521 Kg
Net weight
1,521 Kg
Country of origin
ita
Ball valve in nickel-plated brass
with full flow for non-corrosive media such as water, compressed air, oils and petroleum.
Thread ISO 7/1 UNI-EN 10226
Temperature -20°C to +140°C
From PN80 (1/4") to PN16 (4)
Housing in brass CW617N UNI-EN 12165
Ball in chrome-plated brass CW614N UNI-EN 12164
Seat and other seals in PTFE
Handle in plastic-coated aluminum AL UNI5076
