1 1/2 flow control valve Tognella
Flow control valve with flow control in one direction and free flow in the other direction.
_x000D_Adjustment knob with scale
Partnumber:
FT257/5-112
Package size:
1 kpl
Min. order quantity is:
1 kpl
A
G 1.1/2 BSP
B
24 mm
Brand Name
Tognella
C
190 mm
CH
65 mm
D
167 mm
Dimension F
58 mm
E
181 mm
Flow rate nominal LMin
240 lpm
G
35 mm
H
M55x2
Material
Steel
Pressure compensated
No
Pressure max.
320 bar
Sealing material
NBR
Temperature max.
+100 °C
Temperature min.
-20 °C
Thread
G 1.1/2 BSP
Thread form
Female x female
Valve type
Throttle/checkvalve
Package size
1 kpl
Barcode
437843
Gross weight
Kg
Net weight
5,76 Kg
Country of origin
ita
Intrastat code
84812010
Flow control valve with flow control in one direction and free flow in the other direction.
_x000D_Adjustment knob with scale
