Temperature switch BSP1/2" AMP Superseal 1.5 Set point 50C
Temperature switch BSP1/2" AMP Superseal 1.5 Set point 50C
Partnumber:
ILLZTH5069K
Package size:
0 pcs
Min. order quantity is:
1 pcs
Brand Name
ASA
Connection
AMP superseal 1.5
Contact function
Normally open
Material
Brass
Model code
ILLZTH5069K
Mount
All directions
Number of cycles
100000
Oil temperature max.
+100 °C
Oil temperature min.
-20 °C
Protection class
IP 69K
Switching Current
10 A (12, 24, 250 V AC), 12 A (125 V AC)
Temperature activating
+50 °C
Temperature ambient max.
+80 °C
Temperature ambient min.
-20 °C
Temperature differential
10±5 °C
Temperature storage max.
+110
Temperature storage min.
-60
Thread
G 1/2 BSP
Torque tightening
40 Nm
Package size
0 pcs
Barcode
5715803522769
Gross weight
Kg
Net weight
0,10 Kg
Country of origin
aut
Intrastat code
84186900
Temperature switch BSP1/2" AMP Superseal 1.5 Set point 50C
